LED Spotlight EcoMax
You are here
LED Spotlight EcoMax
Benefits:
• New designed optical reflector with COB chips provides clean light beam
• Aluminum heat sink ensure lifetime up to 30000hrs
• Flexible adjustment for accent lighting
Features:
• Clean Beam
• Long Lifespan
• Vertical Rotate 25°
Validations:
Applications
Conference Room
Home
Hospital
School
Shopping Mall
Technical Data
| Specifications Model |
 |
 |
 |
 |
|---|---|---|---|---|
| LEDSpotlightRA-E R110-22W-6500-45D-WH-GP | LEDSpotlightRA-E R110-22W-4000-45D-WH-GP | LEDSpotlightRA-E R110-22W-3000-45D-WH-GP | LEDSpotlightRA-E R90-15W-6500-36D-WH-GP | |
| Optical parameters | ||||
| Color Temperature | 6 500K | 4 000K | 3 000K | 6 500K |
| Lumen | 1 650lm | 1 650lm | 1 540lm | 1 125lm |
| Beam angle | 45 | 45 | 45 | 36 |
| CRI(Ra) | ≥80 | ≥80 | ≥80 | ≥80 |
| Electrical parameters | ||||
| Input voltage range(VAC) | 220-240V | 220-240V | 220-240V | 220-240V |
| Input frequency(Hz) | 50/60Hz | 50/60Hz | 50/60Hz | 50/60Hz |
| Input current(A) | 0.1 | 0.1 | 0.1 | 0.07 |
| Efficacy(lm/W) | 75 | 75 | 70 | 75 |
Packaging information
| Code/Description | Packaging unit | Pieces per unit | Dimensions | Gross weight | Volume |
|---|---|---|---|---|---|
| LEDSpotlightRA-E R75-9W-3000-36D-WH-GP | 30 | 113 × 113 × 80 mm | 0.235 kg | ||
| LEDSpotlightRA-E R75-9W-4000-36D-WH-GP | 30 | 113 × 113 × 80 mm | 0.235 kg | ||
| LEDSpotlightRA-E R75-9W-6500-36D-WH-GP | 30 | 113 × 113 × 80 mm | 0.235 kg | ||
| LEDSpotlightRA-E R90-15W-3000-36D-WH-GP | 30 | 133 × 133 × 92 mm | 0.357 kg | ||
| LEDSpotlightRA-E R90-15W-4000-36D-WH-GP | 30 | 133 × 133 × 92 mm | 0.357 kg | ||
| LEDSpotlightRA-E R90-15W-6500-36D-WH-GP | 30 | 133 × 133 × 92 mm | 0.357 kg | ||
| LEDSpotlightRA-E R110-22W-3000-45D-WH-GP | 30 | 150 × 150 × 105 mm | 0.456 kg | ||
| LEDSpotlightRA-E R110-22W-4000-45D-WH-GP | 30 | 150 × 150 × 105 mm | 0.456 kg | ||
| LEDSpotlightRA-E R110-22W-6500-45D-WH-GP | 30 | 150 × 150 × 105 mm | 0.456 kg |
